Step1: Product
Vishay General Semiconductor - Diodes Division VS-GB75YF120UT
Image shown is a representation only
Manufacturer
Manufacturer No
VS-GB75YF120UT
Package
Module
Packaging
Bulk
Description
IGBT MOD 1200V 100A ECONO2 4PACK
Detailed Description
IGBT Module 1200 V 100 A 480 W Chassis Mount ECONO2 4PACK
DataSheet
Input
Standard
Packaging
Bulk
Part Status
Obsolete
Power - Max
480 W
Manufacturer
Vishay General Semiconductor - Diodes Division
Mounting Type
Chassis Mount
NTC Thermistor
Yes
Package / Case
Module
Base Product Number
GB75
Operating Temperature
150°C (TJ)
Supplier Device Package
ECONO2 4PACK
Vce(on) (Max) @ Vge, Ic
4.5V @ 15V, 100A
Current - Collector (Ic) (Max)
100 A
Current - Collector Cutoff (Max)
250 µA
Voltage - Collector Emitter Breakdown (Max)
1200 V
| Attribute | Value |
|---|---|
| Input | Standard |
| Packaging | Bulk |
| Part Status | Obsolete |
| Power - Max | 480 W |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Mounting Type | Chassis Mount |
| NTC Thermistor | Yes |
| Package / Case | Module |
| Base Product Number | GB75 |
| Operating Temperature | 150°C (TJ) |
| Supplier Device Package | ECONO2 4PACK |
| Vce(on) (Max) @ Vge, Ic | 4.5V @ 15V, 100A |
| Current - Collector (Ic) (Max) | 100 A |
| Current - Collector Cutoff (Max) | 250 µA |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
