Vishay General Semiconductor - Diodes Division VS-40MT120UHTAPBF
Image shown is a representation only
Manufacturer
Manufacturer No
VS-40MT120UHTAPBF
Package
12-MTP Module
Packaging
Tray
Description
IGBT MODULE 1200V 80A 463W MTP
Detailed Description
IGBT Module NPT Half Bridge 1200 V 80 A 463 W Chassis Mount MTP
Input
Standard
IGBT Type
NPT
Packaging
Tray
Part Status
Obsolete
Power - Max
463 W
Manufacturer
Vishay General Semiconductor - Diodes Division
Configuration
Half Bridge
Mounting Type
Chassis Mount
NTC Thermistor
No
Package / Case
12-MTP Module
Base Product Number
40MT120
Operating Temperature
-40°C ~ 150°C (TJ)
Supplier Device Package
MTP
Vce(on) (Max) @ Vge, Ic
4.91V @ 15V, 80A
Current - Collector (Ic) (Max)
80 A
Input Capacitance (Cies) @ Vce
8.28 nF @ 30 V
Current - Collector Cutoff (Max)
250 µA
Voltage - Collector Emitter Breakdown (Max)
1200 V
| Attribute | Value |
|---|---|
| Input | Standard |
| IGBT Type | NPT |
| Packaging | Tray |
| Part Status | Obsolete |
| Power - Max | 463 W |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Configuration | Half Bridge |
| Mounting Type | Chassis Mount |
| NTC Thermistor | No |
| Package / Case | 12-MTP Module |
| Base Product Number | 40MT120 |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | MTP |
| Vce(on) (Max) @ Vge, Ic | 4.91V @ 15V, 80A |
| Current - Collector (Ic) (Max) | 80 A |
| Input Capacitance (Cies) @ Vce | 8.28 nF @ 30 V |
| Current - Collector Cutoff (Max) | 250 µA |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
