Analog Devices Inc./Maxim Integrated PM35S-048-324F
Image shown is a representation only
Manufacturer
Manufacturer No
PM35S-048-324F
Packaging
Bulk
Description
STEPPER MOTORS PERMANENT MAGNET
Detailed Description
Bipolar Stepper Motor Permanent Magnet Frame Size 14 48.0 Step 750 mA 2VDC
DataSheet
Mfr
Analog Devices Inc./Maxim Integrated
Type
Permanent Magnet
Coil Type
Bipolar
Packaging
Bulk
Step Angle
7.5°
Part Status
Obsolete
Coil Resistance
4 Ohms
NEMA Frame Size
14
Voltage - Rated
2VDC
Diameter - Shaft
0.118" (3.00mm)
Size / Dimension
Round - 1.378" Dia (35.00mm)
Termination Style
Wire Leads with Connector
Steps per Revolution
48.0
Current Rating (Amps)
750 mA
Mounting Hole Spacing
1.654" (42.00mm)
Operating Temperature
75°C
Length - Shaft and Bearing
0.394" (10.00mm)
Torque - Holding (oz-in / mNm)
3.89 / 27.46
| Attribute | Value |
|---|---|
| Mfr | Analog Devices Inc./Maxim Integrated |
| Type | Permanent Magnet |
| Coil Type | Bipolar |
| Packaging | Bulk |
| Step Angle | 7.5° |
| Part Status | Obsolete |
| Coil Resistance | 4 Ohms |
| NEMA Frame Size | 14 |
| Voltage - Rated | 2VDC |
| Diameter - Shaft | 0.118" (3.00mm) |
| Size / Dimension | Round - 1.378" Dia (35.00mm) |
| Termination Style | Wire Leads with Connector |
| Steps per Revolution | 48.0 |
| Current Rating (Amps) | 750 mA |
| Mounting Hole Spacing | 1.654" (42.00mm) |
| Operating Temperature | 75°C |
| Length - Shaft and Bearing | 0.394" (10.00mm) |
| Torque - Holding (oz-in / mNm) | 3.89 / 27.46 |
