Step1: Product
Vigortronix VTX-214-015-512
Image shown is a representation only
Manufacturer
Manufacturer No
VTX-214-015-512
Package
4-DIP Module
Packaging
Bulk
Description
AC/DC CONVERTER 12V 15W
Detailed Description
Enclosed AC DC Converters 1 Output 12V 1.25A 85 ~ 305 VAC, 100 ~ 430 VDC Input
DataSheet
Type
Enclosed
Series
VTX-214
Weight
0.121 lb (55.00 g)
Packaging
Bulk
Efficiency
81%
Part Status
Active
Applications
Household Appliances, ITE (Commercial)
Manufacturer
Vigortronix
Mounting Type
Through Hole
Power (Watts)
15 W
Package / Case
4-DIP Module
Approval Agency
EN, IEC, UL
Standard Number
62368-1; 61558-2; 61000
Voltage - Input
85 ~ 305 VAC, 100 ~ 430 VDC
Size / Dimension
2.06" L x 1.07" W x 0.94" H (52.4mm x 27.2mm x 24.0mm)
Number of Outputs
1
Voltage - Output 1
12V
Operating Temperature
-40°C ~ 85°C (With Derating)
Current - Output (Max)
1.25A
| Attribute | Value |
|---|---|
| Type | Enclosed |
| Series | VTX-214 |
| Weight | 0.121 lb (55.00 g) |
| Packaging | Bulk |
| Efficiency | 81% |
| Part Status | Active |
| Applications | Household Appliances, ITE (Commercial) |
| Manufacturer | Vigortronix |
| Mounting Type | Through Hole |
| Power (Watts) | 15 W |
| Package / Case | 4-DIP Module |
| Approval Agency | EN, IEC, UL |
| Standard Number | 62368-1; 61558-2; 61000 |
| Voltage - Input | 85 ~ 305 VAC, 100 ~ 430 VDC |
| Size / Dimension | 2.06" L x 1.07" W x 0.94" H (52.4mm x 27.2mm x 24.0mm) |
| Number of Outputs | 1 |
| Voltage - Output 1 | 12V |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Current - Output (Max) | 1.25A |
