Step1: Product
Vigortronix VTX-214-010-503
Image shown is a representation only
Manufacturer
Manufacturer No
VTX-214-010-503
Package
4-DIP Module
Packaging
Bulk
Description
AC/DC CONVERTER 3.3V 10W
Detailed Description
Enclosed AC DC Converters 1 Output 3.3V 3.03A 85 ~ 305 VAC, 100 ~ 430 VDC Input
DataSheet
Type
Enclosed
Series
VTX-214
Weight
0.106 lb (48.00 g)
Packaging
Bulk
Efficiency
82%
Part Status
Active
Applications
Household Appliances, ITE (Commercial)
Manufacturer
Vigortronix
Mounting Type
Through Hole
Power (Watts)
10 W
Package / Case
4-DIP Module
Approval Agency
EN, IEC, UL
Standard Number
62368-1; 61558-2; 61000
Voltage - Input
85 ~ 305 VAC, 100 ~ 430 VDC
Size / Dimension
1.87" L x 1.06" W x 0.92" H (47.6mm x 26.8mm x 23.5mm)
Number of Outputs
1
Voltage - Output 1
3.3V
Operating Temperature
-40°C ~ 85°C (With Derating)
Current - Output (Max)
3.03A
| Attribute | Value |
|---|---|
| Type | Enclosed |
| Series | VTX-214 |
| Weight | 0.106 lb (48.00 g) |
| Packaging | Bulk |
| Efficiency | 82% |
| Part Status | Active |
| Applications | Household Appliances, ITE (Commercial) |
| Manufacturer | Vigortronix |
| Mounting Type | Through Hole |
| Power (Watts) | 10 W |
| Package / Case | 4-DIP Module |
| Approval Agency | EN, IEC, UL |
| Standard Number | 62368-1; 61558-2; 61000 |
| Voltage - Input | 85 ~ 305 VAC, 100 ~ 430 VDC |
| Size / Dimension | 1.87" L x 1.06" W x 0.92" H (47.6mm x 26.8mm x 23.5mm) |
| Number of Outputs | 1 |
| Voltage - Output 1 | 3.3V |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Current - Output (Max) | 3.03A |
