Vigortronix VTX-101-1606
Image shown is a representation only
Manufacturer
Manufacturer No
VTX-101-1606
Packaging
Bulk
Description
AUDIO XFMR ENCAP MATCH
Detailed Description
800 Impedance Primary Ohms 800CT Impedance Secondary Ohms 1:1CT Audio Transformer 60Hz ~ 25kHz Through Hole
DataSheet
Series
VTX-101
Packaging
Bulk
Part Status
Active
Manufacturer
Vigortronix
Mounting Type
Through Hole
Frequency Range
60Hz ~ 25kHz
Size / Dimension
0.709" L x 0.709" W (18.00mm x 18.00mm)
Transformer Type
Miniature Epoxy Potted
Termination Style
PC Pin
Voltage - Isolation
1500Vrms
Height - Seated (Max)
0.500" (12.70mm)
Impedance - Primary (Ohms)
800
Impedance - Secondary (Ohms)
800CT
DC Resistance (DCR) - Primary
105Ohm
DC Resistance (DCR) - Secondary
134Ohm
Turns Ratio - Primary:Secondary
1:1CT
| Attribute | Value |
|---|---|
| Series | VTX-101 |
| Packaging | Bulk |
| Part Status | Active |
| Manufacturer | Vigortronix |
| Mounting Type | Through Hole |
| Frequency Range | 60Hz ~ 25kHz |
| Size / Dimension | 0.709" L x 0.709" W (18.00mm x 18.00mm) |
| Transformer Type | Miniature Epoxy Potted |
| Termination Style | PC Pin |
| Voltage - Isolation | 1500Vrms |
| Height - Seated (Max) | 0.500" (12.70mm) |
| Impedance - Primary (Ohms) | 800 |
| Impedance - Secondary (Ohms) | 800CT |
| DC Resistance (DCR) - Primary | 105Ohm |
| DC Resistance (DCR) - Secondary | 134Ohm |
| Turns Ratio - Primary:Secondary | 1:1CT |
