Toshiba Semiconductor and Storage SSM6J511NU,LF
Image shown is a representation only
Manufacturer
Manufacturer No
SSM6J511NU,LF
Quantity
15425
Availability
In Stock
Package
6-WDFN Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
MOSFET P-CH 12V 14A 6UDFNB
Detailed Description
P-Channel 12 V 14A (Ta) Surface Mount 6-UDFNB (2x2)
DataSheet
Mfr
Toshiba Semiconductor and Storage
Series
U-MOSVII
FET Type
P-Channel
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Technology
MOSFET (Metal Oxide)
Part Status
Active
Mounting Type
Surface Mount
Package / Case
6-WDFN Exposed Pad
Vgs(th) (Max) @ Id
1V @ 1mA
Base Product Number
SSM6J511
Operating Temperature
-55°C ~ 150°C (TJ)
Rds On (Max) @ Id, Vgs
9.1mOhm @ 4A, 8V
Supplier Device Package
6-UDFNB (2x2)
Gate Charge (Qg) (Max) @ Vgs
47 nC @ 4.5 V
Drain to Source Voltage (Vdss)
12 V
Input Capacitance (Ciss) (Max) @ Vds
3350 pF @ 6 V
Current - Continuous Drain (Id) @ 25°C
14A (Ta)
| Attribute | Value |
|---|---|
| Mfr | Toshiba Semiconductor and Storage |
| Series | U-MOSVII |
| FET Type | P-Channel |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Technology | MOSFET (Metal Oxide) |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 6-WDFN Exposed Pad |
| Vgs(th) (Max) @ Id | 1V @ 1mA |
| Base Product Number | SSM6J511 |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 9.1mOhm @ 4A, 8V |
| Supplier Device Package | 6-UDFNB (2x2) |
| Gate Charge (Qg) (Max) @ Vgs | 47 nC @ 4.5 V |
| Drain to Source Voltage (Vdss) | 12 V |
| Input Capacitance (Ciss) (Max) @ Vds | 3350 pF @ 6 V |
| Current - Continuous Drain (Id) @ 25°C | 14A (Ta) |
