Step1: Product
The Antenna Company AC30026-01
Image shown is a representation only
Manufacturer
Manufacturer No
AC30026-01
Packaging
Tray
Description
ANT GNSS L1 E1 TH STAMPED MTL
Detailed Description
RF ANTENNA Galileo, GLONASS, GNSS, GPS Stamped Metal Solder Through Hole
DataSheet
Gain
5dBi, 5dBi
VSWR
2, 2
Packaging
Tray
Part Status
Active
Power - Max
2 W
Return Loss
-9.5dB, -9.5dB
Termination
Solder
Antenna Type
Stamped Metal
Applications
Galileo, GLONASS, GNSS, GPS
Height (Max)
0.280" (7.00mm)
Manufacturer
The Antenna Company
Mounting Type
Through Hole
Frequency Group
UHF (1GHz ~ 2GHz)
Frequency Range
1.561GHz ~ 1.61GHz
Number of Bands
2
RF Family/Standard
Navigation
Base Product Number
AC30026
Frequency (Center/Band)
1.575GHz, 1.601GHz
| Attribute | Value |
|---|---|
| Gain | 5dBi, 5dBi |
| VSWR | 2, 2 |
| Packaging | Tray |
| Part Status | Active |
| Power - Max | 2 W |
| Return Loss | -9.5dB, -9.5dB |
| Termination | Solder |
| Antenna Type | Stamped Metal |
| Applications | Galileo, GLONASS, GNSS, GPS |
| Height (Max) | 0.280" (7.00mm) |
| Manufacturer | The Antenna Company |
| Mounting Type | Through Hole |
| Frequency Group | UHF (1GHz ~ 2GHz) |
| Frequency Range | 1.561GHz ~ 1.61GHz |
| Number of Bands | 2 |
| RF Family/Standard | Navigation |
| Base Product Number | AC30026 |
| Frequency (Center/Band) | 1.575GHz, 1.601GHz |
