Step1: Product
Signal Transformer CL-50-100
Image shown is a representation only
Manufacturer
Manufacturer No
CL-50-100
Package
Nonstandard
Packaging
Box
Description
INDUCT ARRAY 2COIL 120UH CHA MNT
Detailed Description
Unshielded 2 Coil Inductor Array 500 µH Inductance - Connected in Series 120 µH Inductance - Connected in Parallel 1.1mOhm DC Resistance (DCR) - Parallel 100 A Nonstandard
Datasheet
Height
3.752" (95.30mm)
Series
CL
Packaging
Box
Shielding
Unshielded
Manufacturer
Signal Transformer
Mounting Type
Chassis Mount
Package / Case
Nonstandard
Number of Coils
2
Size / Dimension
4.500" L x 3.752" W (114.30mm x 95.30mm)
Current Rating - Series
50 A
Current Rating - Parallel
100 A
DC Resistance (DCR) - Series
4.3mOhm
DC Resistance (DCR) - Parallel
1.1mOhm
Inductance - Connected In Series
500 µH
Inductance - Connected In Parallel
120 µH
| Attribute | Value |
|---|---|
| Height | 3.752" (95.30mm) |
| Series | CL |
| Packaging | Box |
| Shielding | Unshielded |
| Manufacturer | Signal Transformer |
| Mounting Type | Chassis Mount |
| Package / Case | Nonstandard |
| Number of Coils | 2 |
| Size / Dimension | 4.500" L x 3.752" W (114.30mm x 95.30mm) |
| Current Rating - Series | 50 A |
| Current Rating - Parallel | 100 A |
| DC Resistance (DCR) - Series | 4.3mOhm |
| DC Resistance (DCR) - Parallel | 1.1mOhm |
| Inductance - Connected In Series | 500 µH |
| Inductance - Connected In Parallel | 120 µH |
