Step1: Product
Signal Transformer CL-2-4
Image shown is a representation only
Manufacturer
Manufacturer No
CL-2-4
Package
Nonstandard
Packaging
Box
Description
INDUCT ARRAY 2 COIL 10MH CHA MNT
Detailed Description
Unshielded 2 Coil Inductor Array 40 mH Inductance - Connected in Series 10 mH Inductance - Connected in Parallel 180mOhm DC Resistance (DCR) - Parallel 4 A Nonstandard
DataSheet
Height
2.752" (69.90mm)
Series
CL
Packaging
Box
Shielding
Unshielded
Part Status
Active
Manufacturer
Signal Transformer
Mounting Type
Chassis Mount
Package / Case
Nonstandard
Number of Coils
2
Size / Dimension
3.126" L x 2.122" W (79.40mm x 53.90mm)
Current Rating - Series
2 A
Current Rating - Parallel
4 A
DC Resistance (DCR) - Series
700mOhm
DC Resistance (DCR) - Parallel
180mOhm
Inductance - Connected In Series
40 mH
Inductance - Connected In Parallel
10 mH
| Attribute | Value |
|---|---|
| Height | 2.752" (69.90mm) |
| Series | CL |
| Packaging | Box |
| Shielding | Unshielded |
| Part Status | Active |
| Manufacturer | Signal Transformer |
| Mounting Type | Chassis Mount |
| Package / Case | Nonstandard |
| Number of Coils | 2 |
| Size / Dimension | 3.126" L x 2.122" W (79.40mm x 53.90mm) |
| Current Rating - Series | 2 A |
| Current Rating - Parallel | 4 A |
| DC Resistance (DCR) - Series | 700mOhm |
| DC Resistance (DCR) - Parallel | 180mOhm |
| Inductance - Connected In Series | 40 mH |
| Inductance - Connected In Parallel | 10 mH |
