Step1: Product
Nisshinbo Micro Devices Inc. NT1191GEAE3S
Image shown is a representation only
Manufacturer
Manufacturer No
NT1191GEAE3S
Quantity
110
Availability
In Stock
Package
6-VFDFN Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
IC AMP GALI 1.164-1.61GHZ 6DFN
Detailed Description
RF Amplifier IC Galileo, GLONASS, GNSS, GPS 1.164GHz ~ 1.61GHz DFN1616-6-GE
DataSheet
Gain
19dB
P1dB
-10dBm
RF Type
Galileo, GLONASS, GNSS, GPS
Frequency
1.164GHz ~ 1.61GHz
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Part Status
Active
Manufacturer
Nisshinbo Micro Devices Inc.
Noise Figure
0.75dB
Mounting Type
Surface Mount, Wettable Flank
Package / Case
6-VFDFN Exposed Pad
Test Frequency
1.575GHz
Current - Supply
5.5mA
Voltage - Supply
1.5V ~ 5.5V
Supplier Device Package
DFN1616-6-GE
| Attribute | Value |
|---|---|
| Gain | 19dB |
| P1dB | -10dBm |
| RF Type | Galileo, GLONASS, GNSS, GPS |
| Frequency | 1.164GHz ~ 1.61GHz |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Part Status | Active |
| Manufacturer | Nisshinbo Micro Devices Inc. |
| Noise Figure | 0.75dB |
| Mounting Type | Surface Mount, Wettable Flank |
| Package / Case | 6-VFDFN Exposed Pad |
| Test Frequency | 1.575GHz |
| Current - Supply | 5.5mA |
| Voltage - Supply | 1.5V ~ 5.5V |
| Supplier Device Package | DFN1616-6-GE |
