Step1: Product
Nisshinbo Micro Devices Inc. NJG1187KG1-TE3
Image shown is a representation only
Manufacturer
Manufacturer No
NJG1187KG1-TE3
Package
6-XFDFN Exposed Pad
Packaging
Tape & Reel (TR)
Description
IC RF AMP GNSS 6ESON
Detailed Description
RF Amplifier IC GNSS 1.164GHz ~ 1.3GHz, 1.559GHz ~ 1.61GHz 6-ESON (1.6x1.6)
DataSheet
Gain
38dB
P1dB
13dBm
RF Type
GNSS
Frequency
1.164GHz ~ 1.3GHz, 1.559GHz ~ 1.61GHz
Packaging
Tape & Reel (TR)
Part Status
Active
Manufacturer
Nisshinbo Micro Devices Inc.
Noise Figure
0.6dB
Mounting Type
Surface Mount
Package / Case
6-XFDFN Exposed Pad
Test Frequency
1.575GHz
Current - Supply
8mA
Voltage - Supply
1.5V ~ 3.7V
Base Product Number
NJG1187
Supplier Device Package
6-ESON (1.6x1.6)
| Attribute | Value |
|---|---|
| Gain | 38dB |
| P1dB | 13dBm |
| RF Type | GNSS |
| Frequency | 1.164GHz ~ 1.3GHz, 1.559GHz ~ 1.61GHz |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Manufacturer | Nisshinbo Micro Devices Inc. |
| Noise Figure | 0.6dB |
| Mounting Type | Surface Mount |
| Package / Case | 6-XFDFN Exposed Pad |
| Test Frequency | 1.575GHz |
| Current - Supply | 8mA |
| Voltage - Supply | 1.5V ~ 3.7V |
| Base Product Number | NJG1187 |
| Supplier Device Package | 6-ESON (1.6x1.6) |
