Step1: Product
Amphenol ICC (FCI) DCM37S500M
Image shown is a representation only
Manufacturer
Manufacturer No
DCM37S500M
Packaging
Tray
Description
CONN D-SUB RCPT 37POS R/A SOLDER
Detailed Description
37 Position D-Sub Receptacle, Female Sockets Connector
DataSheet
Mfr
Amphenol ICC (FCI)
Series
DM HE501
Features
Mounting Brackets
Packaging
Tray
Part Status
Active
Termination
Solder
Contact Type
Signal
Mounting Type
Through Hole, Right Angle
Connector Type
Receptacle, Female Sockets
Contact Finish
Gold
Flange Feature
Housing/Shell (Unthreaded)
Number of Rows
2
Voltage Rating
300V
Backset Spacing
0.406" (10.30mm)
Connector Style
D-Sub
Contact Material
Phosphor Bronze
Base Product Number
DCM37
Dielectric Material
Thermoplastic
Number of Positions
37
Current Rating (Amps)
7.5A per Contact
Operating Temperature
-55°C ~ 125°C
Shell Material, Finish
Steel, Yellow Cadmium Plated
Material Flammability Rating
UL94 V-0
Shell Size, Connector Layout
4 (DC, C)
| Attribute | Value |
|---|---|
| Mfr | Amphenol ICC (FCI) |
| Series | DM HE501 |
| Features | Mounting Brackets |
| Packaging | Tray |
| Part Status | Active |
| Termination | Solder |
| Contact Type | Signal |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Flange Feature | Housing/Shell (Unthreaded) |
| Number of Rows | 2 |
| Voltage Rating | 300V |
| Backset Spacing | 0.406" (10.30mm) |
| Connector Style | D-Sub |
| Contact Material | Phosphor Bronze |
| Base Product Number | DCM37 |
| Dielectric Material | Thermoplastic |
| Number of Positions | 37 |
| Current Rating (Amps) | 7.5A per Contact |
| Operating Temperature | -55°C ~ 125°C |
| Shell Material, Finish | Steel, Yellow Cadmium Plated |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 4 (DC, C) |
