Step1: Product
Cinch Connectivity Solutions DCM37S
Image shown is a representation only
Manufacturer
Manufacturer No
DCM37S
Quantity
3
Availability
In Stock
Packaging
Bulk
Description
CONN D-SUB RCPT 37POS SOLDER CUP
Detailed Description
37 Position D-Sub Receptacle, Female Sockets Connector
DataSheet
Mfr
Cinch Connectivity Solutions
Color
Green
Series
1
Packaging
Bulk
Part Status
Active
Termination
Solder Cup
Contact Form
Machined
Contact Type
Signal
Mounting Type
Free Hanging (In-Line)
Connector Type
Receptacle, Female Sockets
Contact Finish
Gold
Flange Feature
Housing/Shell (Unthreaded)
Number of Rows
2
Connector Style
D-Sub
Contact Material
Phosphor Bronze
Base Product Number
DCM37
Dielectric Material
Diallyl Phthalate (DAP), Glass Filled
Number of Positions
37
Current Rating (Amps)
5A
Operating Temperature
-65°C ~ 125°C
Shell Material, Finish
Steel, Yellow Chromate Plated Zinc
Contact Finish Thickness
30.0µin (0.76µm)
Material Flammability Rating
UL94 V-0
Shell Size, Connector Layout
4 (DC, C)
| Attribute | Value |
|---|---|
| Mfr | Cinch Connectivity Solutions |
| Color | Green |
| Series | 1 |
| Packaging | Bulk |
| Part Status | Active |
| Termination | Solder Cup |
| Contact Form | Machined |
| Contact Type | Signal |
| Mounting Type | Free Hanging (In-Line) |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Flange Feature | Housing/Shell (Unthreaded) |
| Number of Rows | 2 |
| Connector Style | D-Sub |
| Contact Material | Phosphor Bronze |
| Base Product Number | DCM37 |
| Dielectric Material | Diallyl Phthalate (DAP), Glass Filled |
| Number of Positions | 37 |
| Current Rating (Amps) | 5A |
| Operating Temperature | -65°C ~ 125°C |
| Shell Material, Finish | Steel, Yellow Chromate Plated Zinc |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 4 (DC, C) |
