Step1: Product
Yokowo Manufacturing of America, LLC. YOZ-52570ZZ01-YM
Image shown is a representation only
Manufacturer
Manufacturer No
YOZ-52570ZZ01-YM
Packaging
Bulk
Description
GNSS Antenna L1 L2
Detailed Description
RF ANTENNA Beidou, GLONASS, GNSS, GPS Omni-Directional SMA Male (1) Adhesive
DataSheet
Gain
29.2dBic, 29.5dBic, 29.4dBic, 27.9dBic, 26.3dBic, 25.8dBic
VSWR
1.8, 3.0, 1.9, 1.8, 2.1, 1.4
Grade
Automotive
Series
High Precision GNSS Antenna
Features
Cable - 5m
Packaging
Bulk
Part Status
Active
Return Loss
-10.9dB, -6.0dB, -10.2dB, -10.9dB, -9.0dB, -15.6dB
Termination
SMA Male (1)
Antenna Type
Omni-Directional
Applications
Beidou, GLONASS, GNSS, GPS
Height (Max)
2.220" (56.40mm)
Manufacturer
Yokowo Manufacturing of America, LLC.
Mounting Type
Adhesive
Frequency Group
L Band (1GHz ~ 2GHz)
Frequency Range
1.197GHz ~ 1.25GHz, 1.559GHz ~ 1.606GHz
Number of Bands
6
Ingress Protection
IP67
RF Family/Standard
Navigation
Frequency (Center/Band)
1.207GHz, 1.228GHz,1.246GHz, 1.561GHz, 1.575GHz, 1.602GHz
| Attribute | Value |
|---|---|
| Gain | 29.2dBic, 29.5dBic, 29.4dBic, 27.9dBic, 26.3dBic, 25.8dBic |
| VSWR | 1.8, 3.0, 1.9, 1.8, 2.1, 1.4 |
| Grade | Automotive |
| Series | High Precision GNSS Antenna |
| Features | Cable - 5m |
| Packaging | Bulk |
| Part Status | Active |
| Return Loss | -10.9dB, -6.0dB, -10.2dB, -10.9dB, -9.0dB, -15.6dB |
| Termination | SMA Male (1) |
| Antenna Type | Omni-Directional |
| Applications | Beidou, GLONASS, GNSS, GPS |
| Height (Max) | 2.220" (56.40mm) |
| Manufacturer | Yokowo Manufacturing of America, LLC. |
| Mounting Type | Adhesive |
| Frequency Group | L Band (1GHz ~ 2GHz) |
| Frequency Range | 1.197GHz ~ 1.25GHz, 1.559GHz ~ 1.606GHz |
| Number of Bands | 6 |
| Ingress Protection | IP67 |
| RF Family/Standard | Navigation |
| Frequency (Center/Band) | 1.207GHz, 1.228GHz,1.246GHz, 1.561GHz, 1.575GHz, 1.602GHz |
