Step1: Product
Weidmüller 2652030000
Image shown is a representation only
Manufacturer
Manufacturer No
2652030000
Packaging
Bulk
Description
TPS 5.08/15/90 5.0SN GN BX
Detailed Description
15 Position Wire to Board Terminal Block Horizontal with Board 0.200" (5.08mm) Through Hole
DataSheet
Color
Green
Pitch
0.200" (5.08mm)
Series
TPS
Current
15 A
Voltage
300 V
Features
Interlocking (Side)
Packaging
Bulk
Wire Gauge
12-30 AWG
Part Status
Last Time Buy
Manufacturer
Weidmüller
Screw Thread
M3
Mounting Type
Through Hole
Torque - Screw
0.5-0.55 Nm (4.4-4.9 Lb-In)
Housing Material
Polyamide (PA), Nylon
Number of Levels
1
Wire Termination
Screw - Clamping Yoke, Tension Sleeve
Mating Orientation
Horizontal with Board
Positions Per Level
15
Operating Temperature
-40°C ~ 105°C
Contact Material - Plating
Copper Alloy - Tin Plated
| Attribute | Value |
|---|---|
| Color | Green |
| Pitch | 0.200" (5.08mm) |
| Series | TPS |
| Current | 15 A |
| Voltage | 300 V |
| Features | Interlocking (Side) |
| Packaging | Bulk |
| Wire Gauge | 12-30 AWG |
| Part Status | Last Time Buy |
| Manufacturer | Weidmüller |
| Screw Thread | M3 |
| Mounting Type | Through Hole |
| Torque - Screw | 0.5-0.55 Nm (4.4-4.9 Lb-In) |
| Housing Material | Polyamide (PA), Nylon |
| Number of Levels | 1 |
| Wire Termination | Screw - Clamping Yoke, Tension Sleeve |
| Mating Orientation | Horizontal with Board |
| Positions Per Level | 15 |
| Operating Temperature | -40°C ~ 105°C |
| Contact Material - Plating | Copper Alloy - Tin Plated |
