Step1: Product
Texas Instruments DRV8912QPWPRQ1
Image shown is a representation only
Manufacturer
Manufacturer No
DRV8912QPWPRQ1
Quantity
1,115
Availability
In Stock
Package
24-PowerTSSOP (0.173", 4.40mm Width)
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
AUTO MULTI-CHANNEL HALF BRIDGER
Detailed Description
Half Bridge (12) Driver DC Motors, General Purpose MOSFET (Metal Oxide) 24-HTSSOP
Datasheet
Grade
Automotive
Features
Charge Pump, Slew Rate Controlled
Interface
Logic, PWM, SPI
Load Type
Inductive, Capacitive, Resistive
Packaging
Tape & Reel (TR); Cut Tape (CT)
Technology
MOSFET (Metal Oxide)
Applications
DC Motors, General Purpose
Manufacturer
Texas Instruments
Rds On (Typ)
750mOhm LS, 750mOhm HS
Mounting Type
Surface Mount
Qualification
AEC-Q100
Package / Case
24-PowerTSSOP (0.173", 4.40mm Width)
Voltage - Load
4.5V ~ 32V
Fault Protection
Over Current, Over Voltage, UVLO
Voltage - Supply
3V ~ 5.5V
Base Product Number
DRV8912
Output Configuration
Half Bridge (12)
Operating Temperature
-40°C ~ 125°C (TA)
Supplier Device Package
24-HTSSOP
Current - Output / Channel
6A
| Attribute | Value |
|---|---|
| Grade | Automotive |
| Features | Charge Pump, Slew Rate Controlled |
| Interface | Logic, PWM, SPI |
| Load Type | Inductive, Capacitive, Resistive |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Technology | MOSFET (Metal Oxide) |
| Applications | DC Motors, General Purpose |
| Manufacturer | Texas Instruments |
| Rds On (Typ) | 750mOhm LS, 750mOhm HS |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q100 |
| Package / Case | 24-PowerTSSOP (0.173", 4.40mm Width) |
| Voltage - Load | 4.5V ~ 32V |
| Fault Protection | Over Current, Over Voltage, UVLO |
| Voltage - Supply | 3V ~ 5.5V |
| Base Product Number | DRV8912 |
| Output Configuration | Half Bridge (12) |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Supplier Device Package | 24-HTSSOP |
| Current - Output / Channel | 6A |
