Texas Instruments DRV8412DDWR
Image shown is a representation only
Manufacturer
Manufacturer No
DRV8412DDWR
Quantity
1801
Availability
In Stock
Package
44-PowerTSSOP (0.244", 6.20mm Width)
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
IC HALF BRIDGE DRVR 3A 44HTSSOP
Detailed Description
Half Bridge (4) Driver DC Motors, Stepper Motors Power MOSFET 44-HTSSOP
DataSheet
Features
Status Flag
Interface
PWM
Load Type
Inductive
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Technology
Power MOSFET
Part Status
Active
Applications
DC Motors, Stepper Motors
Manufacturer
Texas Instruments
Rds On (Typ)
110mOhm LS, 110mOhm HS
Mounting Type
Surface Mount
Package / Case
44-PowerTSSOP (0.244", 6.20mm Width)
Voltage - Load
0V ~ 52.5V
Fault Protection
Current Limiting, Over Temperature, Short Circuit, UVLO
Voltage - Supply
10.8V ~ 13.2V
Base Product Number
DRV8412
Output Configuration
Half Bridge (4)
Current - Peak Output
6A
Operating Temperature
-40°C ~ 150°C (TJ)
Supplier Device Package
44-HTSSOP
Current - Output / Channel
3A
| Attribute | Value |
|---|---|
| Features | Status Flag |
| Interface | PWM |
| Load Type | Inductive |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Technology | Power MOSFET |
| Part Status | Active |
| Applications | DC Motors, Stepper Motors |
| Manufacturer | Texas Instruments |
| Rds On (Typ) | 110mOhm LS, 110mOhm HS |
| Mounting Type | Surface Mount |
| Package / Case | 44-PowerTSSOP (0.244", 6.20mm Width) |
| Voltage - Load | 0V ~ 52.5V |
| Fault Protection | Current Limiting, Over Temperature, Short Circuit, UVLO |
| Voltage - Supply | 10.8V ~ 13.2V |
| Base Product Number | DRV8412 |
| Output Configuration | Half Bridge (4) |
| Current - Peak Output | 6A |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | 44-HTSSOP |
| Current - Output / Channel | 3A |
