Step1: Product
TE Connectivity 1379030-3
Image shown is a representation only
Manufacturer
Manufacturer No
1379030-3
Packaging
Box
Description
12POS MQS .63 HEADER 90DEG
Detailed Description
Connector Header Through Hole, Right Angle 12 position 0.100" (2.54mm)
DataSheet
Mfr
TE Connectivity
Style
Board to Cable/Wire
Features
Board Lock, Mounting Flange
Packaging
Box
Shrouding
Shrouded - 4 Wall
Part Status
Active
Termination
Solder
Contact Type
Male Pin
Contact Shape
Square
Mounting Type
Through Hole, Right Angle
Connector Type
Header
Fastening Type
Friction Lock
Number of Rows
2
Pitch - Mating
0.100" (2.54mm)
Voltage Rating
12V
Contact Material
Copper Alloy
Insulation Color
Brown
Insulation Height
0.776" (19.70mm)
Base Product Number
1379030
Insulation Material
Polybutylene Terephthalate (PBT), Glass Filled
Number of Positions
12
Row Spacing - Mating
0.100" (2.54mm)
Contact Finish - Post
Tin
Operating Temperature
-40°C ~ 85°C
Contact Finish - Mating
Tin
Number of Positions Loaded
All
Material Flammability Rating
UL94 HB
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity |
| Style | Board to Cable/Wire |
| Features | Board Lock, Mounting Flange |
| Packaging | Box |
| Shrouding | Shrouded - 4 Wall |
| Part Status | Active |
| Termination | Solder |
| Contact Type | Male Pin |
| Contact Shape | Square |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Header |
| Fastening Type | Friction Lock |
| Number of Rows | 2 |
| Pitch - Mating | 0.100" (2.54mm) |
| Voltage Rating | 12V |
| Contact Material | Copper Alloy |
| Insulation Color | Brown |
| Insulation Height | 0.776" (19.70mm) |
| Base Product Number | 1379030 |
| Insulation Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Number of Positions | 12 |
| Row Spacing - Mating | 0.100" (2.54mm) |
| Contact Finish - Post | Tin |
| Operating Temperature | -40°C ~ 85°C |
| Contact Finish - Mating | Tin |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 HB |
