TE Connectivity 1318699-3
Image shown is a representation only
Manufacturer
Manufacturer No
1318699-3
Packaging
Box
Description
MR HDR ASSY 12P COATING
Detailed Description
Connector Header Through Hole 12 position 0.165" (4.20mm)
DataSheet
Mfr
TE Connectivity
Style
Board to Cable/Wire
Packaging
Box
Shrouding
Shrouded - 4 Wall
Part Status
Active
Termination
Solder
Contact Type
Male Pin
Contact Shape
Circular
Mounting Type
Through Hole
Connector Type
Header
Fastening Type
Latch Lock
Number of Rows
4
Pitch - Mating
0.165" (4.20mm)
Voltage Rating
250VAC
Contact Material
Phosphor Bronze
Insulation Color
Black
Base Product Number
1318699
Insulation Material
Polyamide (PA66), Nylon 6/6
Number of Positions
12
Row Spacing - Mating
0.165" (4.20mm)
Contact Finish - Post
Tin-Lead
Contact Length - Post
0.149" (3.78mm)
Current Rating (Amps)
5A
Operating Temperature
-55°C ~ 85°C
Contact Finish - Mating
Gold
Number of Positions Loaded
All
Material Flammability Rating
UL94 V-0
Contact Finish Thickness - Mating
3.00µin (0.076µm)
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity |
| Style | Board to Cable/Wire |
| Packaging | Box |
| Shrouding | Shrouded - 4 Wall |
| Part Status | Active |
| Termination | Solder |
| Contact Type | Male Pin |
| Contact Shape | Circular |
| Mounting Type | Through Hole |
| Connector Type | Header |
| Fastening Type | Latch Lock |
| Number of Rows | 4 |
| Pitch - Mating | 0.165" (4.20mm) |
| Voltage Rating | 250VAC |
| Contact Material | Phosphor Bronze |
| Insulation Color | Black |
| Base Product Number | 1318699 |
| Insulation Material | Polyamide (PA66), Nylon 6/6 |
| Number of Positions | 12 |
| Row Spacing - Mating | 0.165" (4.20mm) |
| Contact Finish - Post | Tin-Lead |
| Contact Length - Post | 0.149" (3.78mm) |
| Current Rating (Amps) | 5A |
| Operating Temperature | -55°C ~ 85°C |
| Contact Finish - Mating | Gold |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Mating | 3.00µin (0.076µm) |
