Step1: Product
TE Connectivity 1376366-8
Image shown is a representation only
Manufacturer
Manufacturer No
1376366-8
Packaging
Box
Description
025 8POS CAP ASSY H TIN
Detailed Description
Connector Header Through Hole, Right Angle 8 position 0.087" (2.20mm)
DataSheet
Mfr
TE Connectivity
Style
Board to Cable/Wire
Series
.025
Features
Mounting Brackets
Packaging
Box
Shrouding
Shrouded - 4 Wall
Part Status
Active
Termination
Solder
Contact Type
Male Pin
Contact Shape
Square
Mounting Type
Through Hole, Right Angle
Connector Type
Header
Fastening Type
Latch Holder
Number of Rows
1
Pitch - Mating
0.087" (2.20mm)
Contact Material
Brass
Insulation Color
Natural
Insulation Height
0.492" (12.50mm)
Base Product Number
1376366
Insulation Material
Syndiotactic Polystyrene (SPS), Glass Filled
Number of Positions
8
Contact Finish - Post
Tin
Contact Length - Post
0.157" (4.00mm)
Current Rating (Amps)
5A
Operating Temperature
-30°C ~ 100°C
Contact Finish - Mating
Tin
Contact Length - Mating
0.217" (5.50mm)
Number of Positions Loaded
All
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity |
| Style | Board to Cable/Wire |
| Series | .025 |
| Features | Mounting Brackets |
| Packaging | Box |
| Shrouding | Shrouded - 4 Wall |
| Part Status | Active |
| Termination | Solder |
| Contact Type | Male Pin |
| Contact Shape | Square |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Header |
| Fastening Type | Latch Holder |
| Number of Rows | 1 |
| Pitch - Mating | 0.087" (2.20mm) |
| Contact Material | Brass |
| Insulation Color | Natural |
| Insulation Height | 0.492" (12.50mm) |
| Base Product Number | 1376366 |
| Insulation Material | Syndiotactic Polystyrene (SPS), Glass Filled |
| Number of Positions | 8 |
| Contact Finish - Post | Tin |
| Contact Length - Post | 0.157" (4.00mm) |
| Current Rating (Amps) | 5A |
| Operating Temperature | -30°C ~ 100°C |
| Contact Finish - Mating | Tin |
| Contact Length - Mating | 0.217" (5.50mm) |
| Number of Positions Loaded | All |
