TE Connectivity Aerospace, Defense and Marine 531721-8
Image shown is a representation only
Manufacturer
Manufacturer No
531721-8
Packaging
Bulk
Description
CONN HEADER R/A 100P 2.54MM
Detailed Description
Connector Header Through Hole, Right Angle 100 position 0.100" (2.54mm)
DataSheet
Mfr
TE Connectivity Aerospace, Defense and Marine
Style
Board to Board or Cable
Series
Military, MIL-DTL-55302, 1001 Box
Features
Mating Guide, Mounting Flange
Packaging
Bulk
Shrouding
Shrouded - 3 Wall
Part Status
Active
Termination
Solder
Applications
General Purpose, Military
Contact Type
Male Pin
Contact Shape
Square
Mounting Type
Through Hole, Right Angle
Connector Type
Header
Number of Rows
2
Pitch - Mating
0.100" (2.54mm)
Contact Material
Brass
Insulation Color
Blue
Insulation Height
0.330" (8.38mm)
Base Product Number
531721
Insulation Material
Polyester, Glass Filled
Number of Positions
100
Row Spacing - Mating
0.100" (2.54mm)
Contact Finish - Post
Tin-Lead
Contact Length - Post
0.135" (3.43mm)
Contact Finish - Mating
Gold
Contact Length - Mating
0.181" (4.60mm)
Number of Positions Loaded
All
Contact Finish Thickness - Mating
50.0µin (1.27µm)
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity Aerospace, Defense and Marine |
| Style | Board to Board or Cable |
| Series | Military, MIL-DTL-55302, 1001 Box |
| Features | Mating Guide, Mounting Flange |
| Packaging | Bulk |
| Shrouding | Shrouded - 3 Wall |
| Part Status | Active |
| Termination | Solder |
| Applications | General Purpose, Military |
| Contact Type | Male Pin |
| Contact Shape | Square |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Header |
| Number of Rows | 2 |
| Pitch - Mating | 0.100" (2.54mm) |
| Contact Material | Brass |
| Insulation Color | Blue |
| Insulation Height | 0.330" (8.38mm) |
| Base Product Number | 531721 |
| Insulation Material | Polyester, Glass Filled |
| Number of Positions | 100 |
| Row Spacing - Mating | 0.100" (2.54mm) |
| Contact Finish - Post | Tin-Lead |
| Contact Length - Post | 0.135" (3.43mm) |
| Contact Finish - Mating | Gold |
| Contact Length - Mating | 0.181" (4.60mm) |
| Number of Positions Loaded | All |
| Contact Finish Thickness - Mating | 50.0µin (1.27µm) |
