Step1: Product
Tamura TTC-272N
Image shown is a representation only
Manufacturer
Manufacturer No
TTC-272N
Packaging
Bulk
Description
MODEM TRANSFORMERS
Detailed Description
600 Impedance Primary Ohms 600 Impedance Secondary Ohms Audio Transformer 300Hz ~ 3.5kHz Through Hole
Packaging
Bulk
Part Status
Active
Power Level
-45dB ~ 7dB
Return Loss
26dB
Manufacturer
Tamura
Mounting Type
Through Hole
Insertion Loss
1dB
Approval Agency
CSA, UR
Frequency Range
300Hz ~ 3.5kHz
Size / Dimension
0.780" L x 0.654" W (19.80mm x 16.60mm)
Transformer Type
Audio Coupling
Termination Style
PC Pin
Frequency Response
±0.5dB
Voltage - Isolation
1500V
Height - Seated (Max)
0.500" (12.70mm)
Impedance - Primary (Ohms)
600
Impedance - Secondary (Ohms)
600
DC Resistance (DCR) - Primary
46Ohm
DC Resistance (DCR) - Secondary
63Ohm
| Attribute | Value |
|---|---|
| Packaging | Bulk |
| Part Status | Active |
| Power Level | -45dB ~ 7dB |
| Return Loss | 26dB |
| Manufacturer | Tamura |
| Mounting Type | Through Hole |
| Insertion Loss | 1dB |
| Approval Agency | CSA, UR |
| Frequency Range | 300Hz ~ 3.5kHz |
| Size / Dimension | 0.780" L x 0.654" W (19.80mm x 16.60mm) |
| Transformer Type | Audio Coupling |
| Termination Style | PC Pin |
| Frequency Response | ±0.5dB |
| Voltage - Isolation | 1500V |
| Height - Seated (Max) | 0.500" (12.70mm) |
| Impedance - Primary (Ohms) | 600 |
| Impedance - Secondary (Ohms) | 600 |
| DC Resistance (DCR) - Primary | 46Ohm |
| DC Resistance (DCR) - Secondary | 63Ohm |
