Step1: Product
Tamura TTC-198
Image shown is a representation only
Manufacturer
Manufacturer No
TTC-198
Description
AUDIO XFMR 600 / 600CT
Detailed Description
600 Impedance Primary Ohms 600CT Impedance Secondary Ohms 1:1 Audio Transformer 300Hz ~ 3.5kHz
Series
TTC
Part Status
Obsolete
Power Level
-45dB ~ 7dB
Return Loss
26dB Min
Manufacturer
Tamura
Insertion Loss
1.4dB Max @ 1kHz
Frequency Range
300Hz ~ 3.5kHz
Frequency Response
±0.5dB
Voltage - Isolation
4000VRMS @ 1 Minute
Impedance - Primary (Ohms)
600
Impedance - Secondary (Ohms)
600CT
DC Resistance (DCR) - Primary
33Ohm
DC Resistance (DCR) - Secondary
56Ohm
Turns Ratio - Primary:Secondary
1:1
| Attribute | Value |
|---|---|
| Series | TTC |
| Part Status | Obsolete |
| Power Level | -45dB ~ 7dB |
| Return Loss | 26dB Min |
| Manufacturer | Tamura |
| Insertion Loss | 1.4dB Max @ 1kHz |
| Frequency Range | 300Hz ~ 3.5kHz |
| Frequency Response | ±0.5dB |
| Voltage - Isolation | 4000VRMS @ 1 Minute |
| Impedance - Primary (Ohms) | 600 |
| Impedance - Secondary (Ohms) | 600CT |
| DC Resistance (DCR) - Primary | 33Ohm |
| DC Resistance (DCR) - Secondary | 56Ohm |
| Turns Ratio - Primary:Secondary | 1:1 |
