Step1: Product
Pulse Electronics P0401NL
Image shown is a representation only
Manufacturer
Manufacturer No
P0401NL
Package
Nonstandard
Packaging
Tube
Description
INDUCT ARRAY 2 COIL 27.4UH SMD
Detailed Description
Unshielded 2 Coil Inductor Array 109.8 µH Inductance - Connected in Series 27.4 µH Inductance - Connected in Parallel 38.15mOhm DC Resistance (DCR) - Parallel 4.4 A Nonstandard
Datasheet
Height
0.310" (7.87mm)
Series
Tomcat
Packaging
Tube
Shielding
Unshielded
Tolerance
±20%
Manufacturer
Pulse Electronics
Mounting Type
Surface Mount
Package / Case
Nonstandard
Number of Coils
2
Size / Dimension
0.715" L x 0.590" W (18.16mm x 14.99mm)
Operating Temperature
-40°C ~ 130°C
Current Rating - Series
2.2 A
Current Rating - Parallel
4.4 A
DC Resistance (DCR) - Series
152.6mOhm
DC Resistance (DCR) - Parallel
38.15mOhm
Inductance - Connected In Series
109.8 µH
Inductance - Connected In Parallel
27.4 µH
| Attribute | Value |
|---|---|
| Height | 0.310" (7.87mm) |
| Series | Tomcat |
| Packaging | Tube |
| Shielding | Unshielded |
| Tolerance | ±20% |
| Manufacturer | Pulse Electronics |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Number of Coils | 2 |
| Size / Dimension | 0.715" L x 0.590" W (18.16mm x 14.99mm) |
| Operating Temperature | -40°C ~ 130°C |
| Current Rating - Series | 2.2 A |
| Current Rating - Parallel | 4.4 A |
| DC Resistance (DCR) - Series | 152.6mOhm |
| DC Resistance (DCR) - Parallel | 38.15mOhm |
| Inductance - Connected In Series | 109.8 µH |
| Inductance - Connected In Parallel | 27.4 µH |
