Step1: Product
NXP USA Inc. NX3DV3899HRZ
Image shown is a representation only
Manufacturer
Manufacturer No
NX3DV3899HRZ
Quantity
50
Availability
In Stock
Package
16-XFQFN Exposed Pad
Packaging
Tape & Reel (TR)
Description
IC SWITCH DPDTX2 3.3OHM 16HXQFN
Detailed Description
2 Circuit IC Switch 2:2 3.3Ohm 16-HXQFN (3x3)
Datasheet
Grade
Automotive
Crosstalk
-90dB @ 1MHz
Packaging
Tape & Reel (TR)
Manufacturer
NXP USA Inc.
Mounting Type
Surface Mount
Qualification
AEC-Q100
-3db Bandwidth
200MHz
Package / Case
16-XFQFN Exposed Pad
Switch Circuit
DPDT
Charge Injection
4pC
Number of Circuits
2
Base Product Number
NX3DV3899
Operating Temperature
-40°C ~ 125°C (TA)
Supplier Device Package
16-HXQFN (3x3)
On-State Resistance (Max)
3.3Ohm
Switch Time (Ton, Toff) (Max)
40ns, 20ns
Voltage - Supply, Single (V+)
1.4V ~ 4.3V
Current - Leakage (IS(off)) (Max)
5nA
Multiplexer/Demultiplexer Circuit
2:2
Channel-to-Channel Matching (ΔRon)
700mOhm
Channel Capacitance (CS(off), CD(off))
8pF
| Attribute | Value |
|---|---|
| Grade | Automotive |
| Crosstalk | -90dB @ 1MHz |
| Packaging | Tape & Reel (TR) |
| Manufacturer | NXP USA Inc. |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q100 |
| -3db Bandwidth | 200MHz |
| Package / Case | 16-XFQFN Exposed Pad |
| Switch Circuit | DPDT |
| Charge Injection | 4pC |
| Number of Circuits | 2 |
| Base Product Number | NX3DV3899 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Supplier Device Package | 16-HXQFN (3x3) |
| On-State Resistance (Max) | 3.3Ohm |
| Switch Time (Ton, Toff) (Max) | 40ns, 20ns |
| Voltage - Supply, Single (V+) | 1.4V ~ 4.3V |
| Current - Leakage (IS(off)) (Max) | 5nA |
| Multiplexer/Demultiplexer Circuit | 2:2 |
| Channel-to-Channel Matching (ΔRon) | 700mOhm |
| Channel Capacitance (CS(off), CD(off)) | 8pF |
