Step1: Product
Murata Power Solutions Inc. 54200C
Image shown is a representation only
Manufacturer
Manufacturer No
54200C
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
CURR SENSE XFMR 1:1:200 15A SMD
Detailed Description
1:1:200 Current Sense Transformer 50kHz ~ 500kHz 7mOhm Primary, 6.6Ohm Secondary 60 mH Surface Mount
Datasheet
Type
Invasive
Series
5400
Packaging
Tape & Reel (TR); Cut Tape (CT)
Inductance
60 mH
Manufacturer
Murata Power Solutions Inc.
Mounting Type
Surface Mount
Frequency Range
50kHz ~ 500kHz
Size / Dimension
0.354" L x 0.425" W (9.00mm x 10.80mm)
Termination Style
Gull Wing
Base Product Number
54
DC Resistance (DCR)
7mOhm Primary, 6.6Ohm Secondary
Height - Seated (Max)
0.323" (8.20mm)
Turns Ratio - Primary:Secondary
1:1:200
| Attribute | Value |
|---|---|
| Type | Invasive |
| Series | 5400 |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Inductance | 60 mH |
| Manufacturer | Murata Power Solutions Inc. |
| Mounting Type | Surface Mount |
| Frequency Range | 50kHz ~ 500kHz |
| Size / Dimension | 0.354" L x 0.425" W (9.00mm x 10.80mm) |
| Termination Style | Gull Wing |
| Base Product Number | 54 |
| DC Resistance (DCR) | 7mOhm Primary, 6.6Ohm Secondary |
| Height - Seated (Max) | 0.323" (8.20mm) |
| Turns Ratio - Primary:Secondary | 1:1:200 |
