Step1: Product
Molex 2200981671
Image shown is a representation only
Manufacturer
Manufacturer No
2200981671
Quantity
30
Availability
In Stock
Packaging
Tray
Description
1.25WB MLP SGL RA TH ASSY 16CKT
Detailed Description
Connector Header Through Hole, Right Angle 16 position 0.049" (1.25mm)
DataSheet
Mfr
Molex
Style
Board to Cable/Wire
Series
Micro-Lock Plus 1.25mm
Features
Board Guide, Pick and Place
Packaging
Tray
Shrouding
Shrouded - 4 Wall
Part Status
Active
Termination
Solder
Contact Type
Male Pin
Contact Shape
Rectangular
Mounting Type
Through Hole, Right Angle
Connector Type
Header
Fastening Type
Locking Ramp
Number of Rows
1
Pitch - Mating
0.049" (1.25mm)
Voltage Rating
50VAC/DC
Contact Material
Brass
Insulation Color
Black
Insulation Height
0.152" (3.85mm)
Insulation Material
Polyamide (PA), Nylon, Glass Filled
Number of Positions
16
Contact Finish - Post
Tin
Contact Length - Post
0.091" (2.30mm)
Current Rating (Amps)
Varies by Wire Gauge
Operating Temperature
-40°C ~ 105°C
Contact Finish - Mating
Tin
Number of Positions Loaded
All
Material Flammability Rating
UL94 V-0
| Attribute | Value |
|---|---|
| Mfr | Molex |
| Style | Board to Cable/Wire |
| Series | Micro-Lock Plus 1.25mm |
| Features | Board Guide, Pick and Place |
| Packaging | Tray |
| Shrouding | Shrouded - 4 Wall |
| Part Status | Active |
| Termination | Solder |
| Contact Type | Male Pin |
| Contact Shape | Rectangular |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Header |
| Fastening Type | Locking Ramp |
| Number of Rows | 1 |
| Pitch - Mating | 0.049" (1.25mm) |
| Voltage Rating | 50VAC/DC |
| Contact Material | Brass |
| Insulation Color | Black |
| Insulation Height | 0.152" (3.85mm) |
| Insulation Material | Polyamide (PA), Nylon, Glass Filled |
| Number of Positions | 16 |
| Contact Finish - Post | Tin |
| Contact Length - Post | 0.091" (2.30mm) |
| Current Rating (Amps) | Varies by Wire Gauge |
| Operating Temperature | -40°C ~ 105°C |
| Contact Finish - Mating | Tin |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 V-0 |
