Molex 2200980571
Image shown is a representation only
Manufacturer
Manufacturer No
2200980571
Quantity
187
Availability
In Stock
Packaging
Tray
Description
1.25WB MLP SGL RA TH ASSY 5CKT B
Detailed Description
Connector Header Through Hole, Right Angle 5 position 0.049" (1.25mm)
Datasheet
Mfr
Molex
Style
Board to Cable/Wire
Series
Micro-Lock Plus 1.25mm
Features
Board Guide, Pick and Place
Packaging
Tray
Shrouding
Shrouded - 4 Wall
Termination
Solder
Contact Type
Male Pin
Contact Shape
Rectangular
Mounting Type
Through Hole, Right Angle
Connector Type
Header
Fastening Type
Locking Ramp
Number of Rows
1
Pitch - Mating
0.049" (1.25mm)
Voltage Rating
50VAC/DC
Contact Material
Brass
Insulation Color
Black
Insulation Height
0.152" (3.85mm)
Insulation Material
Polyamide (PA), Nylon, Glass Filled
Number of Positions
5
Contact Finish - Post
Tin
Contact Length - Post
0.091" (2.30mm)
Current Rating (Amps)
Varies by Wire Gauge
Operating Temperature
-40°C ~ 105°C
Contact Finish - Mating
Tin
Number of Positions Loaded
All
Material Flammability Rating
UL94 V-0
| Attribute | Value |
|---|---|
| Mfr | Molex |
| Style | Board to Cable/Wire |
| Series | Micro-Lock Plus 1.25mm |
| Features | Board Guide, Pick and Place |
| Packaging | Tray |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact Type | Male Pin |
| Contact Shape | Rectangular |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Header |
| Fastening Type | Locking Ramp |
| Number of Rows | 1 |
| Pitch - Mating | 0.049" (1.25mm) |
| Voltage Rating | 50VAC/DC |
| Contact Material | Brass |
| Insulation Color | Black |
| Insulation Height | 0.152" (3.85mm) |
| Insulation Material | Polyamide (PA), Nylon, Glass Filled |
| Number of Positions | 5 |
| Contact Finish - Post | Tin |
| Contact Length - Post | 0.091" (2.30mm) |
| Current Rating (Amps) | Varies by Wire Gauge |
| Operating Temperature | -40°C ~ 105°C |
| Contact Finish - Mating | Tin |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 V-0 |
