Step1: Product
Laird-Signal Integrity Products CM2022X330R-10
Image shown is a representation only
Manufacturer
Manufacturer No
CM2022X330R-10
Package
Horizontal, 4 Flat Lead
Packaging
Tape & Reel (TR)
Description
CMC 10A 2LN 33 OHM SMD
Detailed Description
2 Line Common Mode Choke Surface Mount 33 Ohms @ 100 MHz 10A DCR 0.75mOhm
Datasheet
Series
CM
Packaging
Tape & Reel (TR)
Height (Max)
0.130" (3.30mm)
Manufacturer
Laird-Signal Integrity Products
Mounting Type
Surface Mount
Package / Case
Horizontal, 4 Flat Lead
Number of Lines
2
Size / Dimension
0.264" L x 0.224" W (6.70mm x 5.70mm)
Current Rating (Max)
10A
Impedance @ Frequency
33 Ohms @ 100 MHz
DC Resistance (DCR) (Max)
0.75mOhm
| Attribute | Value |
|---|---|
| Series | CM |
| Packaging | Tape & Reel (TR) |
| Height (Max) | 0.130" (3.30mm) |
| Manufacturer | Laird-Signal Integrity Products |
| Mounting Type | Surface Mount |
| Package / Case | Horizontal, 4 Flat Lead |
| Number of Lines | 2 |
| Size / Dimension | 0.264" L x 0.224" W (6.70mm x 5.70mm) |
| Current Rating (Max) | 10A |
| Impedance @ Frequency | 33 Ohms @ 100 MHz |
| DC Resistance (DCR) (Max) | 0.75mOhm |
