Fairchild Semiconductor FAN5776UCX
Image shown is a representation only
Manufacturer
Manufacturer No
FAN5776UCX
Package
12-UFBGA, WLCSP
Packaging
Bulk
Description
IC LED DRV RGLTR PWM 12WLCSP
Detailed Description
LED Driver IC 5 Output DC DC Regulator Step-Up (Boost) PWM Dimming 25mA 12-WLCSP (1.42x1.66)
DataSheet
Type
DC DC Regulator
Dimming
PWM
Topology
Step-Up (Boost)
Frequency
1.8MHz
Packaging
Bulk
Part Status
Active
Applications
Backlight
Manufacturer
Fairchild Semiconductor
Mounting Type
Surface Mount
Package / Case
12-UFBGA, WLCSP
Voltage - Output
3.5V ~ 8.5V
Number of Outputs
5
Internal Switch(s)
Yes
Base Product Number
FAN5776
Operating Temperature
-40°C ~ 85°C (TA)
Voltage - Supply (Max)
5.5V
Voltage - Supply (Min)
2.3V
Supplier Device Package
12-WLCSP (1.42x1.66)
Current - Output / Channel
25mA
| Attribute | Value |
|---|---|
| Type | DC DC Regulator |
| Dimming | PWM |
| Topology | Step-Up (Boost) |
| Frequency | 1.8MHz |
| Packaging | Bulk |
| Part Status | Active |
| Applications | Backlight |
| Manufacturer | Fairchild Semiconductor |
| Mounting Type | Surface Mount |
| Package / Case | 12-UFBGA, WLCSP |
| Voltage - Output | 3.5V ~ 8.5V |
| Number of Outputs | 5 |
| Internal Switch(s) | Yes |
| Base Product Number | FAN5776 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Supply (Min) | 2.3V |
| Supplier Device Package | 12-WLCSP (1.42x1.66) |
| Current - Output / Channel | 25mA |
