Espressif Systems ESP8685H2
Image shown is a representation only
Manufacturer
Manufacturer No
ESP8685H2
Package
28-VFQFN Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
IC RF TXRX+MCU WIFI 28QFN
Detailed Description
IC RF TxRx + MCU WiFi 802.11b/g/n, Bluetooth v5.0 2.4GHz 28-VFQFN Exposed Pad
DataSheet
Mfr
Espressif Systems
GPIO
15
Type
TxRx + MCU
Series
ESP8685
Protocol
802.11b/g/n, Bluetooth v5.0
Frequency
2.4GHz
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Memory Size
2MB Flash, 384kB RAM, 400kB SRAM
Part Status
Obsolete
Sensitivity
-97dBm
Mounting Type
Surface Mount
Package / Case
28-VFQFN Exposed Pad
Power - Output
19dBm
Data Rate (Max)
150Mbps
Voltage - Supply
3V ~ 3.6V
Serial Interfaces
ADC, GPIO, I2C, I2S, PWM, SPI, UART, USB
RF Family/Standard
WiFi
Base Product Number
ESP8685
Current - Receiving
84mA ~ 87mA
DigiKey Programmable
Not Verified
Operating Temperature
-40°C ~ 105°C (TA)
Current - Transmitting
276mA ~ 335mA
Supplier Device Package
28-QFN (4x4)
| Attribute | Value |
|---|---|
| Mfr | Espressif Systems |
| GPIO | 15 |
| Type | TxRx + MCU |
| Series | ESP8685 |
| Protocol | 802.11b/g/n, Bluetooth v5.0 |
| Frequency | 2.4GHz |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Memory Size | 2MB Flash, 384kB RAM, 400kB SRAM |
| Part Status | Obsolete |
| Sensitivity | -97dBm |
| Mounting Type | Surface Mount |
| Package / Case | 28-VFQFN Exposed Pad |
| Power - Output | 19dBm |
| Data Rate (Max) | 150Mbps |
| Voltage - Supply | 3V ~ 3.6V |
| Serial Interfaces | ADC, GPIO, I2C, I2S, PWM, SPI, UART, USB |
| RF Family/Standard | WiFi |
| Base Product Number | ESP8685 |
| Current - Receiving | 84mA ~ 87mA |
| DigiKey Programmable | Not Verified |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Current - Transmitting | 276mA ~ 335mA |
| Supplier Device Package | 28-QFN (4x4) |
