Diodes Incorporated DMN2990UFA-7B
Image shown is a representation only
Manufacturer
Manufacturer No
DMN2990UFA-7B
Quantity
5930
Availability
In Stock
Package
3-XFDFN
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
MOSFET N-CH 20V 510MA 3DFN
Detailed Description
N-Channel 20 V 510mA (Ta) 400mW (Ta) Surface Mount X2-DFN0806-3
DataSheet
Mfr
Diodes Incorporated
FET Type
N-Channel
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Vgs (Max)
±8V
Technology
MOSFET (Metal Oxide)
Part Status
Active
Mounting Type
Surface Mount
Package / Case
3-XFDFN
Vgs(th) (Max) @ Id
1V @ 250µA
Base Product Number
DMN2990
Operating Temperature
-55°C ~ 150°C (TJ)
Rds On (Max) @ Id, Vgs
990mOhm @ 100mA, 4.5V
Power Dissipation (Max)
400mW (Ta)
Supplier Device Package
X2-DFN0806-3
Gate Charge (Qg) (Max) @ Vgs
0.5 nC @ 4.5 V
Drain to Source Voltage (Vdss)
20 V
Input Capacitance (Ciss) (Max) @ Vds
27.6 pF @ 16 V
Drive Voltage (Max Rds On, Min Rds On)
1.2V, 4.5V
Current - Continuous Drain (Id) @ 25°C
510mA (Ta)
| Attribute | Value |
|---|---|
| Mfr | Diodes Incorporated |
| FET Type | N-Channel |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Vgs (Max) | ±8V |
| Technology | MOSFET (Metal Oxide) |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 3-XFDFN |
| Vgs(th) (Max) @ Id | 1V @ 250µA |
| Base Product Number | DMN2990 |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 990mOhm @ 100mA, 4.5V |
| Power Dissipation (Max) | 400mW (Ta) |
| Supplier Device Package | X2-DFN0806-3 |
| Gate Charge (Qg) (Max) @ Vgs | 0.5 nC @ 4.5 V |
| Drain to Source Voltage (Vdss) | 20 V |
| Input Capacitance (Ciss) (Max) @ Vds | 27.6 pF @ 16 V |
| Drive Voltage (Max Rds On, Min Rds On) | 1.2V, 4.5V |
| Current - Continuous Drain (Id) @ 25°C | 510mA (Ta) |
