Diodes Incorporated DMG1012T-7
Image shown is a representation only
Manufacturer
Manufacturer No
DMG1012T-7
Quantity
65310
Availability
In Stock
Package
SOT-523
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
MOSFET N-CH 20V 630MA SOT-523
Detailed Description
N-Channel 20 V 630mA (Ta) 280mW (Ta) Surface Mount SOT-523
DataSheet
Mfr
Diodes Incorporated
FET Type
N-Channel
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Vgs (Max)
±6V
Technology
MOSFET (Metal Oxide)
Part Status
Active
Mounting Type
Surface Mount
Package / Case
SOT-523
Vgs(th) (Max) @ Id
1V @ 250µA
Base Product Number
DMG1012
Operating Temperature
-55°C ~ 150°C (TJ)
Rds On (Max) @ Id, Vgs
400mOhm @ 600mA, 4.5V
Power Dissipation (Max)
280mW (Ta)
Supplier Device Package
SOT-523
Gate Charge (Qg) (Max) @ Vgs
0.74 nC @ 4.5 V
Drain to Source Voltage (Vdss)
20 V
Input Capacitance (Ciss) (Max) @ Vds
60.67 pF @ 16 V
Drive Voltage (Max Rds On, Min Rds On)
1.8V, 4.5V
Current - Continuous Drain (Id) @ 25°C
630mA (Ta)
| Attribute | Value |
|---|---|
| Mfr | Diodes Incorporated |
| FET Type | N-Channel |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Vgs (Max) | ±6V |
| Technology | MOSFET (Metal Oxide) |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | SOT-523 |
| Vgs(th) (Max) @ Id | 1V @ 250µA |
| Base Product Number | DMG1012 |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 400mOhm @ 600mA, 4.5V |
| Power Dissipation (Max) | 280mW (Ta) |
| Supplier Device Package | SOT-523 |
| Gate Charge (Qg) (Max) @ Vgs | 0.74 nC @ 4.5 V |
| Drain to Source Voltage (Vdss) | 20 V |
| Input Capacitance (Ciss) (Max) @ Vds | 60.67 pF @ 16 V |
| Drive Voltage (Max Rds On, Min Rds On) | 1.8V, 4.5V |
| Current - Continuous Drain (Id) @ 25°C | 630mA (Ta) |
