Step1: Product
Cornell Dubilier Knowles 106K100CB4G-FA
Image shown is a representation only
Manufacturer
Manufacturer No
106K100CB4G-FA
Package
14-SMD, Gull Wing
Packaging
Tape & Reel (TR)
Description
FILM/M
Detailed Description
10 µF Film Capacitor 80V 100V Polyester, Metallized 14-SMD, Gull Wing
DataSheet
Mfr
Cornell Dubilier Knowles
Series
CB
Features
Low ESR, Low ESL
Packaging
Tape & Reel (TR)
Tolerance
±10%
Capacitance
10 µF
Part Status
Active
Applications
DC Link, DC Filtering; High Frequency, Switching
Lead Spacing
0.400" (10.16mm)
Mounting Type
Surface Mount
Package / Case
14-SMD, Gull Wing
Size / Dimension
0.996" L x 0.500" W (25.30mm x 12.70mm)
Dielectric Material
Polyester, Metallized
Voltage Rating - AC
80V
Voltage Rating - DC
100V
Height - Seated (Max)
0.248" (6.30mm)
Operating Temperature
-55°C ~ 125°C
ESR (Equivalent Series Resistance)
3 mOhms
| Attribute | Value |
|---|---|
| Mfr | Cornell Dubilier Knowles |
| Series | CB |
| Features | Low ESR, Low ESL |
| Packaging | Tape & Reel (TR) |
| Tolerance | ±10% |
| Capacitance | 10 µF |
| Part Status | Active |
| Applications | DC Link, DC Filtering; High Frequency, Switching |
| Lead Spacing | 0.400" (10.16mm) |
| Mounting Type | Surface Mount |
| Package / Case | 14-SMD, Gull Wing |
| Size / Dimension | 0.996" L x 0.500" W (25.30mm x 12.70mm) |
| Dielectric Material | Polyester, Metallized |
| Voltage Rating - AC | 80V |
| Voltage Rating - DC | 100V |
| Height - Seated (Max) | 0.248" (6.30mm) |
| Operating Temperature | -55°C ~ 125°C |
| ESR (Equivalent Series Resistance) | 3 mOhms |
