Step1: Product
Paktron 106K100RA6-FA
Image shown is a representation only
Manufacturer
Manufacturer No
106K100RA6-FA
Package
Radial
Packaging
Bulk
Description
CAPACITOR MLP 10UF 100V RADIAL
Detailed Description
10 µF Film Capacitor 80V 100V Polyester, Metallized Radial
DataSheet
Mfr
Paktron
Series
Angstor®
Features
Low ESR, High Temperature
Packaging
Bulk
Tolerance
±10%
Capacitance
10 µF
Part Status
Active
Termination
PC Pins
Applications
EMI, RFI Suppression; High Pulse, DV/DT
Lead Spacing
0.591" (15.00mm)
Mounting Type
Through Hole
Package / Case
Radial
Size / Dimension
0.650" L x 0.260" W (16.50mm x 6.60mm)
Dielectric Material
Polyester, Metallized
Voltage Rating - AC
80V
Voltage Rating - DC
100V
Height - Seated (Max)
0.461" (11.70mm)
Operating Temperature
-55°C ~ 125°C
ESR (Equivalent Series Resistance)
5 mOhms
| Attribute | Value |
|---|---|
| Mfr | Paktron |
| Series | Angstor® |
| Features | Low ESR, High Temperature |
| Packaging | Bulk |
| Tolerance | ±10% |
| Capacitance | 10 µF |
| Part Status | Active |
| Termination | PC Pins |
| Applications | EMI, RFI Suppression; High Pulse, DV/DT |
| Lead Spacing | 0.591" (15.00mm) |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.650" L x 0.260" W (16.50mm x 6.60mm) |
| Dielectric Material | Polyester, Metallized |
| Voltage Rating - AC | 80V |
| Voltage Rating - DC | 100V |
| Height - Seated (Max) | 0.461" (11.70mm) |
| Operating Temperature | -55°C ~ 125°C |
| ESR (Equivalent Series Resistance) | 5 mOhms |
