Step1: Product
American Zettler AZ9871-1A-12DET
Image shown is a representation only
Manufacturer
Manufacturer No
AZ9871-1A-12DET
Packaging
Tube
Description
RELAY AUTOMOTIVE SPST 30A 12V
Detailed Description
Automotive Relay SPST-NO (1 Form A) 12VDC Coil Through Hole
Datasheet
Series
AZ9871
Features
Sealed - Epoxy
Coil Type
Non Latching
Packaging
Tube
Coil Power
567mW
Coil Current
47.2 mA
Coil Voltage
12VDC
Contact Form
SPST-NO (1 Form A)
Manufacturer
American Zettler
Operate Time
3 ms
Release Time
1.5 ms
Mounting Type
Through Hole
Coil Resistance
254 Ohms
Contact Material
Silver Tin Oxide (AgSnO)
Switching Voltage
24VDC - Max
Termination Style
PC Pin
Base Product Number
AZ9871
Must Operate Voltage
6.9 VDC
Must Release Voltage
1.5 VDC
Operating Temperature
-40°C ~ 105°C
Contact Rating (Current)
30 A
| Attribute | Value |
|---|---|
| Series | AZ9871 |
| Features | Sealed - Epoxy |
| Coil Type | Non Latching |
| Packaging | Tube |
| Coil Power | 567mW |
| Coil Current | 47.2 mA |
| Coil Voltage | 12VDC |
| Contact Form | SPST-NO (1 Form A) |
| Manufacturer | American Zettler |
| Operate Time | 3 ms |
| Release Time | 1.5 ms |
| Mounting Type | Through Hole |
| Coil Resistance | 254 Ohms |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Switching Voltage | 24VDC - Max |
| Termination Style | PC Pin |
| Base Product Number | AZ9871 |
| Must Operate Voltage | 6.9 VDC |
| Must Release Voltage | 1.5 VDC |
| Operating Temperature | -40°C ~ 105°C |
| Contact Rating (Current) | 30 A |
