Step1: Product
American Zettler AZ987-1C-24DET
Image shown is a representation only
Manufacturer
Manufacturer No
AZ987-1C-24DET
Packaging
Box
Description
RELAY AUTOMOTIVE SPDT 30A 24V
Detailed Description
Automotive Relay SPDT (1 Form C) 24VDC Coil Through Hole
DataSheet
Series
AZ987
Features
Sealed - Epoxy
Coil Type
Non Latching
Packaging
Box
Part Status
Active
Coil Voltage
24VDC
Contact Form
SPDT (1 Form C)
Manufacturer
American Zettler
Operate Time
4 ms
Release Time
2 ms
Mounting Type
Through Hole
Contact Material
Silver Tin Oxide (AgSnO)
Switching Voltage
16VDC - Max
Termination Style
PC Pin
Must Operate Voltage
13.8 VDC
Must Release Voltage
3 VDC
Operating Temperature
-40°C ~ 105°C
Contact Rating (Current)
30 A
| Attribute | Value |
|---|---|
| Series | AZ987 |
| Features | Sealed - Epoxy |
| Coil Type | Non Latching |
| Packaging | Box |
| Part Status | Active |
| Coil Voltage | 24VDC |
| Contact Form | SPDT (1 Form C) |
| Manufacturer | American Zettler |
| Operate Time | 4 ms |
| Release Time | 2 ms |
| Mounting Type | Through Hole |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Switching Voltage | 16VDC - Max |
| Termination Style | PC Pin |
| Must Operate Voltage | 13.8 VDC |
| Must Release Voltage | 3 VDC |
| Operating Temperature | -40°C ~ 105°C |
| Contact Rating (Current) | 30 A |
