Step1: Product
Allied Components International FWPQ2814L-3R3K
Image shown is a representation only
Manufacturer
Manufacturer No
FWPQ2814L-3R3K
Package
2-SMD, Gull Wing
Packaging
Tray
Description
FIXED IND 3.3UH 30A 1.62 MOHM
Detailed Description
3.3 µH Shielded Wirewound Inductor 30 A 1.62mOhm Max 2-SMD, Gull Wing
Datasheet
Mfr
Allied Components International
Type
Wirewound
Series
FWPQ2814L
Packaging
Tray
Shielding
Shielded
Tolerance
±10%
Inductance
3.3 µH
Mounting Type
Surface Mount
Package / Case
2-SMD, Gull Wing
Size / Dimension
1.102" L x 0.760" W (28.00mm x 19.30mm)
DC Resistance (DCR)
1.62mOhm Max
Current Rating (Amps)
30 A
Height - Seated (Max)
0.571" (14.50mm)
Operating Temperature
-40°C ~ 85°C
Supplier Device Package
2-SMD
Frequency - Self Resonant
40MHz
Current - Saturation (Isat)
57A
Inductance Frequency - Test
500 kHz
| Attribute | Value |
|---|---|
| Mfr | Allied Components International |
| Type | Wirewound |
| Series | FWPQ2814L |
| Packaging | Tray |
| Shielding | Shielded |
| Tolerance | ±10% |
| Inductance | 3.3 µH |
| Mounting Type | Surface Mount |
| Package / Case | 2-SMD, Gull Wing |
| Size / Dimension | 1.102" L x 0.760" W (28.00mm x 19.30mm) |
| DC Resistance (DCR) | 1.62mOhm Max |
| Current Rating (Amps) | 30 A |
| Height - Seated (Max) | 0.571" (14.50mm) |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 2-SMD |
| Frequency - Self Resonant | 40MHz |
| Current - Saturation (Isat) | 57A |
| Inductance Frequency - Test | 500 kHz |
