Vishay Semiconductor Opto Division 6N138-X007
Image shown is a representation only
Manufacturer
Manufacturer No
6N138-X007
Package
8-SMD, Gull Wing
Packaging
Tube
Description
OPTOISO 5.3KV DARL W/BASE 8-SMD
Detailed Description
Optoisolator Darlington with Base Output 5300Vrms 1 Channel 8-SMD
DataSheet
Packaging
Tube
Input Type
DC
Output Type
Darlington with Base
Part Status
Obsolete
Manufacturer
Vishay Semiconductor Opto Division
Mounting Type
Surface Mount
Package / Case
8-SMD, Gull Wing
Number of Channels
1
Base Product Number
6N138
Voltage - Isolation
5300Vrms
Operating Temperature
-55°C ~ 100°C
Voltage - Output (Max)
7V
Supplier Device Package
8-SMD
Current - Output / Channel
60mA
Current Transfer Ratio (Min)
300% @ 1.6mA
Voltage - Forward (Vf) (Typ)
1.4V
Turn On / Turn Off Time (Typ)
2µs, 2µs
Current - DC Forward (If) (Max)
25 mA
| Attribute | Value |
|---|---|
| Packaging | Tube |
| Input Type | DC |
| Output Type | Darlington with Base |
| Part Status | Obsolete |
| Manufacturer | Vishay Semiconductor Opto Division |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD, Gull Wing |
| Number of Channels | 1 |
| Base Product Number | 6N138 |
| Voltage - Isolation | 5300Vrms |
| Operating Temperature | -55°C ~ 100°C |
| Voltage - Output (Max) | 7V |
| Supplier Device Package | 8-SMD |
| Current - Output / Channel | 60mA |
| Current Transfer Ratio (Min) | 300% @ 1.6mA |
| Voltage - Forward (Vf) (Typ) | 1.4V |
| Turn On / Turn Off Time (Typ) | 2µs, 2µs |
| Current - DC Forward (If) (Max) | 25 mA |
