Step1: Product
Tusonix a Subsidiary of CTS Electronic Components 4101-500
Image shown is a representation only
Manufacturer No
4101-500
Package
Axial, Eyelet - No Lead
Packaging
Bulk
Description
FILTER LC(PI) 1750PF CUSTOM
Detailed Description
LC (Pi) EMI Filter 3rd Order 1 Channel C = 1750pF 10 A Axial, Eyelet - No Lead
DataSheet
Series
4101
Values
C = 1750pF
Current
10 A
Packaging
Bulk
Technology
LC (Pi)
Part Status
Active
Filter Order
3rd
Manufacturer
Tusonix a Subsidiary of CTS Electronic Components
Mounting Type
Custom
ESD Protection
No
Package / Case
Axial, Eyelet - No Lead
Voltage - Rated
125V
Size / Dimension
0.190" Dia x 0.250" L (4.83mm x 6.35mm)
Attenuation Value
5dB @ 10MHz, 35dB @ 100MHz, 50dB @ 1GHz, 50dB @ 10GHz
Number of Channels
1
| Attribute | Value |
|---|---|
| Series | 4101 |
| Values | C = 1750pF |
| Current | 10 A |
| Packaging | Bulk |
| Technology | LC (Pi) |
| Part Status | Active |
| Filter Order | 3rd |
| Manufacturer | Tusonix a Subsidiary of CTS Electronic Components |
| Mounting Type | Custom |
| ESD Protection | No |
| Package / Case | Axial, Eyelet - No Lead |
| Voltage - Rated | 125V |
| Size / Dimension | 0.190" Dia x 0.250" L (4.83mm x 6.35mm) |
| Attenuation Value | 5dB @ 10MHz, 35dB @ 100MHz, 50dB @ 1GHz, 50dB @ 10GHz |
| Number of Channels | 1 |
