Toshiba Semiconductor and Storage TLP351H(TP1,F)
Image shown is a representation only
Manufacturer
Manufacturer No
TLP351H(TP1,F)
Quantity
1281
Availability
In Stock
Package
8-SMD, Gull Wing
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
OPTOISO 3.75KV 1CH GATE DVR 8SMD
Detailed Description
600mA Gate Driver Optical Coupling 3750Vrms 1 Channel 8-SMD
DataSheet
Mfr
Toshiba Semiconductor and Storage
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Technology
Optical Coupling
Part Status
Active
Mounting Type
Surface Mount
Package / Case
8-SMD, Gull Wing
Approval Agency
CQC, cUR, UR, VDE
Number of Channels
1
Base Product Number
TLP351
Voltage - Isolation
3750Vrms
Current - Peak Output
600mA
Operating Temperature
-40°C ~ 125°C
Rise / Fall Time (Typ)
50ns, 50ns
Supplier Device Package
8-SMD
Voltage - Output Supply
10V ~ 30V
Current - Output High, Low
400mA, 400mA
Pulse Width Distortion (Max)
500ns
Voltage - Forward (Vf) (Typ)
1.55V
Current - DC Forward (If) (Max)
20 mA
Propagation Delay tpLH / tpHL (Max)
700ns, 700ns
Common Mode Transient Immunity (Min)
20kV/µs
| Attribute | Value |
|---|---|
| Mfr | Toshiba Semiconductor and Storage |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Technology | Optical Coupling |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD, Gull Wing |
| Approval Agency | CQC, cUR, UR, VDE |
| Number of Channels | 1 |
| Base Product Number | TLP351 |
| Voltage - Isolation | 3750Vrms |
| Current - Peak Output | 600mA |
| Operating Temperature | -40°C ~ 125°C |
| Rise / Fall Time (Typ) | 50ns, 50ns |
| Supplier Device Package | 8-SMD |
| Voltage - Output Supply | 10V ~ 30V |
| Current - Output High, Low | 400mA, 400mA |
| Pulse Width Distortion (Max) | 500ns |
| Voltage - Forward (Vf) (Typ) | 1.55V |
| Current - DC Forward (If) (Max) | 20 mA |
| Propagation Delay tpLH / tpHL (Max) | 700ns, 700ns |
| Common Mode Transient Immunity (Min) | 20kV/µs |
