Step1: Product
TE Connectivity Raychem Cable Protection DRC13-70PD-B027
Image shown is a representation only
Manufacturer
Manufacturer No
DRC13-70PD-B027
Packaging
Bulk
Description
HDR, 70P, BLK, RA, M5, FLG
Detailed Description
Connector Header Through Hole, Right Angle 70 position 0.215" (5.46mm)
DataSheet
Mfr
TE Connectivity Raychem Cable Protection
Style
Board to Cable/Wire
Series
DRC
Features
Board Guide
Packaging
Bulk
Shrouding
Shrouded - 4 Wall
Part Status
Active
Termination
Solder
Applications
General Purpose
Contact Type
Male Pin
Contact Shape
Circular
Mounting Type
Through Hole, Right Angle
Connector Type
Header
Fastening Type
Push-Pull
Number of Rows
5
Pitch - Mating
0.215" (5.46mm)
Voltage Rating
250VAC/DC
Contact Material
Copper Alloy
Insulation Color
Black
Insulation Height
2.126" (54.00mm)
Insulation Material
Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Positions
70
Contact Length - Post
0.161" (4.09mm)
Current Rating (Amps)
13A
Operating Temperature
-55°C ~ 125°C
Contact Finish - Mating
Nickel
Number of Positions Loaded
All
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity Raychem Cable Protection |
| Style | Board to Cable/Wire |
| Series | DRC |
| Features | Board Guide |
| Packaging | Bulk |
| Shrouding | Shrouded - 4 Wall |
| Part Status | Active |
| Termination | Solder |
| Applications | General Purpose |
| Contact Type | Male Pin |
| Contact Shape | Circular |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Header |
| Fastening Type | Push-Pull |
| Number of Rows | 5 |
| Pitch - Mating | 0.215" (5.46mm) |
| Voltage Rating | 250VAC/DC |
| Contact Material | Copper Alloy |
| Insulation Color | Black |
| Insulation Height | 2.126" (54.00mm) |
| Insulation Material | Polyamide (PA46), Nylon 4/6, Glass Filled |
| Number of Positions | 70 |
| Contact Length - Post | 0.161" (4.09mm) |
| Current Rating (Amps) | 13A |
| Operating Temperature | -55°C ~ 125°C |
| Contact Finish - Mating | Nickel |
| Number of Positions Loaded | All |
