Step1: Product
TE Connectivity AMP Connectors 3-487951-0
Image shown is a representation only
Manufacturer
Manufacturer No
3-487951-0
Packaging
Tape & Reel (TR)
Description
CONN FPC TOP 30POS 1MM R/A
Detailed Description
30 Position FPC Connector Contacts, Top 0.039" (1.00mm) Surface Mount, Right Angle
DataSheet
Pitch
0.039" (1.00mm)
Features
Solder Retention, Zero Insertion Force (ZIF)
Packaging
Tape & Reel (TR)
Part Status
Obsolete
Termination
Solder
Manufacturer
TE Connectivity AMP Connectors
Housing Color
Natural
Mounting Type
Surface Mount, Right Angle
Actuator Color
Black
Cable End Type
Straight
Contact Finish
Tin-Lead
Flat Flex Type
FPC
Voltage Rating
200V
Locking Feature
Slide Lock
Contact Material
Phosphor Bronze
Housing Material
Liquid Crystal Polymer (LCP), Glass Filled
FFC, FCB Thickness
0.30mm
Height Above Board
0.101" (2.56mm)
Base Product Number
487951
Number of Positions
30
Current Rating (Amps)
1A
Operating Temperature
-40°C ~ 85°C
Connector/Contact Type
Contacts, Top
Contact Finish Thickness
150.0µin (3.81µm)
Material Flammability Rating
UL94 V-0
| Attribute | Value |
|---|---|
| Pitch | 0.039" (1.00mm) |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Termination | Solder |
| Manufacturer | TE Connectivity AMP Connectors |
| Housing Color | Natural |
| Mounting Type | Surface Mount, Right Angle |
| Actuator Color | Black |
| Cable End Type | Straight |
| Contact Finish | Tin-Lead |
| Flat Flex Type | FPC |
| Voltage Rating | 200V |
| Locking Feature | Slide Lock |
| Contact Material | Phosphor Bronze |
| Housing Material | Liquid Crystal Polymer (LCP), Glass Filled |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.101" (2.56mm) |
| Base Product Number | 487951 |
| Number of Positions | 30 |
| Current Rating (Amps) | 1A |
| Operating Temperature | -40°C ~ 85°C |
| Connector/Contact Type | Contacts, Top |
| Contact Finish Thickness | 150.0µin (3.81µm) |
| Material Flammability Rating | UL94 V-0 |
