Step1: Product
TE Connectivity AMP Connectors 3-1734742-8
Image shown is a representation only
Manufacturer
Manufacturer No
3-1734742-8
Packaging
Bulk
Description
CONN FFC VERT 38POS 0.5MM SMD
Detailed Description
38 Position FFC, FPC Connector Contacts, Vertical - 1 Sided 0.020" (0.50mm) Surface Mount
Datasheet
Pitch
0.020" (0.50mm)
Features
Solder Retention, Zero Insertion Force (ZIF)
Packaging
Bulk
Termination
Solder
Manufacturer
TE Connectivity AMP Connectors
Housing Color
Black
Mounting Type
Surface Mount
Actuator Color
Brown
Cable End Type
Straight or Tapered
Contact Finish
Gold
Flat Flex Type
FFC, FPC
Voltage Rating
50V
Locking Feature
Slide Lock
Contact Material
Phosphor Bronze
Housing Material
Thermoplastic, Glass Filled
Actuator Material
Thermoplastic
FFC, FCB Thickness
0.30mm
Height Above Board
0.163" (4.15mm)
Base Product Number
1734742
Number of Positions
38
Current Rating (Amps)
0.5A
Operating Temperature
-20°C ~ 85°C
Connector/Contact Type
Contacts, Vertical - 1 Sided
Contact Finish Thickness
Flash
Material Flammability Rating
UL94 V-0
| Attribute | Value |
|---|---|
| Pitch | 0.020" (0.50mm) |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Packaging | Bulk |
| Termination | Solder |
| Manufacturer | TE Connectivity AMP Connectors |
| Housing Color | Black |
| Mounting Type | Surface Mount |
| Actuator Color | Brown |
| Cable End Type | Straight or Tapered |
| Contact Finish | Gold |
| Flat Flex Type | FFC, FPC |
| Voltage Rating | 50V |
| Locking Feature | Slide Lock |
| Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic, Glass Filled |
| Actuator Material | Thermoplastic |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.163" (4.15mm) |
| Base Product Number | 1734742 |
| Number of Positions | 38 |
| Current Rating (Amps) | 0.5A |
| Operating Temperature | -20°C ~ 85°C |
| Connector/Contact Type | Contacts, Vertical - 1 Sided |
| Contact Finish Thickness | Flash |
| Material Flammability Rating | UL94 V-0 |
