Taiwan Semiconductor Corporation TS2509CS
Image shown is a representation only
Manufacturer
Manufacturer No
TS2509CS
Package
8-SOIC (0.154", 3.90mm Width)
Packaging
Tape & Reel (TR)
Description
PWM BUCK CONTROLLER 3A 500KHZ
Detailed Description
Buck Regulator Positive Output Step-Down DC-DC Controller IC 8-SOP
DataSheet
Function
Step-Down
Topology
Buck
Packaging
Tape & Reel (TR)
Clock Sync
No
Output Type
Transistor Driver
Part Status
Active
Manufacturer
Taiwan Semiconductor Corporation
Mounting Type
Surface Mount
Output Phases
1
Package / Case
8-SOIC (0.154", 3.90mm Width)
Control Features
Current Limit, Enable, Soft Start
Duty Cycle (Max)
100%
Number of Outputs
1
Output Configuration
Positive
Frequency - Switching
500kHz
Operating Temperature
-20°C ~ 125°C
Synchronous Rectifier
No
Supplier Device Package
8-SOP
Voltage - Supply (Vcc/Vdd)
3.6V ~ 23V
