Step1: Product
STMicroelectronics STPSC606G-TR
Image shown is a representation only
Manufacturer
Manufacturer No
STPSC606G-TR
Package
TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
DIODE SIL CARBIDE 600V 6A D2PAK
Detailed Description
Diode 600 V 6A Surface Mount D2PAK
DataSheet
Mfr
STMicroelectronics
Speed
Zero Recovery Time > 500mA (Io)
Packaging
Tape & Reel (TR); Cut Tape (CT)
Technology
SiC (Silicon Carbide) Schottky
Part Status
Obsolete
Mounting Type
Surface Mount
Package / Case
TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Base Product Number
STPSC606
Capacitance @ Vr, F
375pF @ 0V, 1MHz
Supplier Device Package
D2PAK
Reverse Recovery Time (trr)
0 ns
Current - Reverse Leakage @ Vr
75 µA @ 600 V
Voltage - DC Reverse (Vr) (Max)
600 V
Current - Average Rectified (Io)
6A
Operating Temperature - Junction
-40°C ~ 175°C
Voltage - Forward (Vf) (Max) @ If
1.7 V @ 6 A
| Attribute | Value |
|---|---|
| Mfr | STMicroelectronics |
| Speed | Zero Recovery Time > 500mA (Io) |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Technology | SiC (Silicon Carbide) Schottky |
| Part Status | Obsolete |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Base Product Number | STPSC606 |
| Capacitance @ Vr, F | 375pF @ 0V, 1MHz |
| Supplier Device Package | D2PAK |
| Reverse Recovery Time (trr) | 0 ns |
| Current - Reverse Leakage @ Vr | 75 µA @ 600 V |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Current - Average Rectified (Io) | 6A |
| Operating Temperature - Junction | -40°C ~ 175°C |
| Voltage - Forward (Vf) (Max) @ If | 1.7 V @ 6 A |
