Step1: Product
STMicroelectronics M74HCT174RM13TR
Image shown is a representation only
Manufacturer
Manufacturer No
M74HCT174RM13TR
Package
16-SOIC (0.154", 3.90mm Width)
Packaging
Tape & Reel (TR)
Description
IC FF D-TYPE SINGLE 6-BIT 16-SO
Detailed Description
Flip Flop 1 Element D-Type 6 Bit Positive Edge 16-SOIC (0.154", 3.90mm Width)
DataSheet
Type
D-Type
Series
74HCT
Function
Master Reset
Packaging
Tape & Reel (TR)
Output Type
Non-Inverted
Part Status
Obsolete
Manufacturer
STMicroelectronics
Trigger Type
Positive Edge
Mounting Type
Surface Mount
Package / Case
16-SOIC (0.154", 3.90mm Width)
Clock Frequency
56 MHz
Voltage - Supply
4.5V ~ 5.5V
Input Capacitance
5 pF
Number of Elements
1
Base Product Number
74HCT174
Operating Temperature
-55°C ~ 125°C (TA)
Supplier Device Package
16-SO
Current - Quiescent (Iq)
4 µA
Current - Output High, Low
4mA, 4mA
Number of Bits per Element
6
Max Propagation Delay @ V, Max CL
28ns @ 4.5V, 50pF
| Attribute | Value |
|---|---|
| Type | D-Type |
| Series | 74HCT |
| Function | Master Reset |
| Packaging | Tape & Reel (TR) |
| Output Type | Non-Inverted |
| Part Status | Obsolete |
| Manufacturer | STMicroelectronics |
| Trigger Type | Positive Edge |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Clock Frequency | 56 MHz |
| Voltage - Supply | 4.5V ~ 5.5V |
| Input Capacitance | 5 pF |
| Number of Elements | 1 |
| Base Product Number | 74HCT174 |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Supplier Device Package | 16-SO |
| Current - Quiescent (Iq) | 4 µA |
| Current - Output High, Low | 4mA, 4mA |
| Number of Bits per Element | 6 |
| Max Propagation Delay @ V, Max CL | 28ns @ 4.5V, 50pF |
