Step1: Product
SMC Diode Solutions MBRB20100CT
Image shown is a representation only
Manufacturer
Manufacturer No
MBRB20100CT
Quantity
15343
Availability
In Stock
Package
TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Packaging
Tape & Reel (TR)
Description
DIODE ARRAY SCHOTTKY 100V D2PAK
Detailed Description
Diode Array 1 Pair Common Cathode 100 V Surface Mount TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
DataSheet
Speed
Fast Recovery =< 500ns, > 200mA (Io)
Packaging
Tape & Reel (TR)
Technology
Schottky
Part Status
Active
Manufacturer
SMC Diode Solutions
Mounting Type
Surface Mount
Package / Case
TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Base Product Number
MBRB20100
Diode Configuration
1 Pair Common Cathode
Supplier Device Package
D2PAK
Current - Reverse Leakage @ Vr
1 mA @ 100 V
Voltage - DC Reverse (Vr) (Max)
100 V
Operating Temperature - Junction
-55°C ~ 150°C
Voltage - Forward (Vf) (Max) @ If
900 mV @ 10 A
| Attribute | Value |
|---|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Packaging | Tape & Reel (TR) |
| Technology | Schottky |
| Part Status | Active |
| Manufacturer | SMC Diode Solutions |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Base Product Number | MBRB20100 |
| Diode Configuration | 1 Pair Common Cathode |
| Supplier Device Package | D2PAK |
| Current - Reverse Leakage @ Vr | 1 mA @ 100 V |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - Forward (Vf) (Max) @ If | 900 mV @ 10 A |
