Step1: Product
Sensitec STK-616Y-20MLB5
Image shown is a representation only
Manufacturer
Manufacturer No
STK-616Y-20MLB5
Package
8-SOIC (0.154", 3.90mm Width)
Packaging
Tape & Reel (TR)
Description
CURRENT SENSOR TMR/OL 20A 8-SOIC
Detailed Description
Current Sensor 20A 1 Channel Magnetoresistive, Open Loop Bidirectional 8-SOIC (0.154", 3.90mm Width)
DataSheet
Mfr
Sensitec
Output
Ratiometric, Voltage
Series
STK-616YM
Accuracy
±1.5%
Frequency
DC ~ 400kHz
Linearity
±1%
Packaging
Tape & Reel (TR)
Part Status
Active
Sensitivity
100mV/A
Sensor Type
Magnetoresistive, Open Loop
Polarization
Bidirectional
For Measuring
AC/DC
Mounting Type
Surface Mount
Response Time
1µs
Package / Case
8-SOIC (0.154", 3.90mm Width)
Voltage - Supply
4.75V ~ 5.25V
Current - Sensing
20A
Number of Channels
1
Operating Temperature
-40°C ~ 125°C
Current - Supply (Max)
6mA
Supplier Device Package
8-SOIC
| Attribute | Value |
|---|---|
| Mfr | Sensitec |
| Output | Ratiometric, Voltage |
| Series | STK-616YM |
| Accuracy | ±1.5% |
| Frequency | DC ~ 400kHz |
| Linearity | ±1% |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Sensitivity | 100mV/A |
| Sensor Type | Magnetoresistive, Open Loop |
| Polarization | Bidirectional |
| For Measuring | AC/DC |
| Mounting Type | Surface Mount |
| Response Time | 1µs |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Voltage - Supply | 4.75V ~ 5.25V |
| Current - Sensing | 20A |
| Number of Channels | 1 |
| Operating Temperature | -40°C ~ 125°C |
| Current - Supply (Max) | 6mA |
| Supplier Device Package | 8-SOIC |
